MAX4653ESE+ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX4653ESE+	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices Inc./Maxim Integrated MAX4653ESE+
Turn-on time: 14ns
Turn-off time: 8ns
Supply Voltage: 1.8V~5.5V
Switch Circuit: SPST(SPST)-Normal Open/Normally closed
Number of Channels: 4
On-State Resistance (Max): 4Ω
Package: SOIC-16
Manufacturer: Analog Devices Inc./Maxim Integrated
Multiplexer/Demultiplexer Circuit: 1:1
Part Status: Active
Charge Injection: 2pC
-3db Bandwidth: -
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply, Dual (V±): -
Supplier Device Package: 16-SOIC
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Switch Time (Ton, Toff) (Max): 14ns, 8ns
Packaging: Tube
Channel-to-Channel Matching (ΔRon): 50mOhm
Voltage - Supply, Single (V+): 1.8V ~ 5.5V
Channel Capacitance (CS(off), CD(off)): 16pF, 16pF
Mounting Type: Surface Mount
Series: -
Crosstalk: -100dB @ 1MHz
Number of Circuits: 4
Current - Leakage (IS(off)) (Max): 100pA
Base Part Number: MAX4653
detail: 4 Circuit IC Switch 1:1 4Ohm 16-SOIC
