- SAM L22 Datasheet Summary
SAM L22 Datasheet Summary Datasheet
Datasheet specifications
| Datasheet's name | SAM L22 Datasheet Summary |
|---|---|
| File size | 2270.736 KB |
| File type | |
| Number of pages | 51 |
Download Datasheet SAM L22 Datasheet Summary |
Download Datasheet |
|---|
Other documentations
Technical specifications
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 8KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: Microchip Tech ATSAML22N16A-CFUT
- PWM (Bit): -
- 8Bit Timer: -
- LCD Module: Yes
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 82
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: LCD/LED Driver;DMA;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 64KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 1.62V~3.63V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: UFBGA-100
- Manufacturer: Microchip Tech
- Series: SAM L22N
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Core Processor: ARM® Cortex®-M0+
- Core Size: 32-Bit
- Speed: 32MHz
- Connectivity: I²C, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
- Number of I/O: 82
- Program Memory Size: 64KB (64K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.63V
- Data Converters: A/D 20x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-UFBGA
- Supplier Device Package: 100-UFBGA (6x6)
- Base Part Number: ATSAML22N
- detail: ARM® Cortex®-M0+ SAM L22N Microcontroller IC 32-Bit 32MHz 64KB (64K x 8) FLASH 100-UFBGA (6x6)
