MAX1974EUB+T دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MAX1974EUB+T	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices Inc./Maxim Integrated MAX1974EUB+T
Output Type: Adjustable
Input Voltage: 2.6V~5.5V
Output Voltage: 0.75V~5.5V
Number of Outputs: 1
Switching Frequency: 1.4MHz
Output Current (Max): 1A
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: UMAX-10
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 5.5V
Voltage - Input (Min): 2.6V
Output Configuration: Positive
Supplier Device Package: 10-uMAX
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Frequency - Switching: 1.4MHz
Current - Output: 1A
Part Status: Active
Series: -
Voltage - Output (Max): 5.5V
Base Part Number: MAX1974
Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Voltage - Output (Min/Fixed): 0.75V (1V, 1.5V)
Packaging: Tube
detail: Buck Switching Regulator IC Positive Adjustable (Programmable) 0.75V (1V, 1.5V) 1 Output 1A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
