MAX4761EWX+T دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX4761EWX+T	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices Inc./Maxim Integrated MAX4761EWX+T
Turn-on time: 140ns
Turn-off time: 50ns
Supply Voltage: 1.8V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 8
On-State Resistance (Max): 3.5Ω
Package: UCSP-36(3x3)
Manufacturer: Analog Devices Inc./Maxim Integrated
Multiplexer/Demultiplexer Circuit: 2:1
Part Status: Active
Charge Injection: 15pC
-3db Bandwidth: 150MHz
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply, Dual (V±): -
Supplier Device Package: 36-UCSP (3x3)
Package / Case: 36-WFBGA, CSPBGA
Switch Time (Ton, Toff) (Max): 140ns, 50ns
Packaging: Tape & Reel (TR)
Channel-to-Channel Matching (ΔRon): 200mOhm
Voltage - Supply, Single (V+): 1.8V ~ 5.5V
Channel Capacitance (CS(off), CD(off)): 25pF
Mounting Type: Surface Mount
Series: -
Crosstalk: -95dB @ 100kHz
Number of Circuits: 8
Current - Leakage (IS(off)) (Max): 5nA
Base Part Number: MAX476
detail: 8 Circuit IC Switch 2:1 3.5Ohm 36-UCSP (3x3)
