دیتاشیت LT1613CS5#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1613 Datasheet |
|---|---|
| حجم فایل | 302.334 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LT1613 Datasheet |
LT1613 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Buck-boost type
- Topology: Boost;Flyback;SEPIC
- Datasheet: Analog Devices LT1613CS5#TRMPBF
- Output Type: Adjustable
- Input Voltage: 0.9V~10V
- Output Voltage: 1.23V~34V
- Number of Outputs: 1
- Switching Frequency: 1.4MHz
- Output Current (Max): 550mA
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SOT-23-5
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 0.9V
- Voltage - Input (Max): 10V
- Voltage - Output (Min/Fixed): 1.23V
- Voltage - Output (Max): 34V
- Current - Output: 550mA (Switch)
- Frequency - Switching: 1.4MHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: SOT-23-5 Thin, TSOT-23-5
- Supplier Device Package: TSOT-23-5
- Base Part Number: LT1613
- detail: Boost, Flyback, SEPIC Switching Regulator IC Positive Adjustable 1.23V 1 Output 550mA (Switch) SOT-23-5 Thin, TSOT-23-5
