دیتاشیت ATF750LVC-15XU
مشخصات دیتاشیت
| نام دیتاشیت |
ATF750LVC
|
| حجم فایل |
436.268
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
19
|
مشخصات
-
RoHS:
true
-
Type:
EEPLD
-
Category:
Single Chip Microcomputer/Microcontroller/Programmable Logic Device (CPLDs/FPGAs)
-
Datasheet:
Microchip Tech ATF750LVC-15XU
-
Logic Array Blocks:
-
-
Number of Logic Gates:
-
-
Logic Elements / Cells:
-
-
Maximum Delay Time Tpd:
15ns
-
Operating Temperature Range:
-40°C~+85°C
-
Supply Voltage Range - VCCIO:
3V~5.5V
-
Package:
TSSOP-24
-
Manufacturer:
Microchip Tech
-
Series:
ATF750LVC
-
Packaging:
Tube
-
Part Status:
Active
-
Programmable Type:
EE PLD
-
Delay Time tpd(1) Max:
15ns
-
Voltage Supply - Internal:
3V ~ 5.5V
-
Number of Macrocells:
10
-
Number of I/O:
10
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
24-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
24-TSSOP
-
Base Part Number:
ATF750
-
detail:
IC CPLD 10MC 15NS 24TSSOP
