MAX4996ETG+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX4996ETG+T |
|---|---|
| حجم فایل | 99.482 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت MAX4996ETG+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX4996(L) 13 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX4996ETG+T
- Turn-on time: 100us
- Turn-off time: 6us
- Supply Voltage: 2.5V~5.5V
- Switch Circuit: DPDT(DPDT)
- Number of Channels: 3
- On-State Resistance (Max): 4Ω
- Package: QFN-24-EP(4x4)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 2:2
- Part Status: Active
- Charge Injection: -
- -3db Bandwidth: 670MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): -
- Supplier Device Package: 24-TQFN (4x4)
- Package / Case: 24-WFQFN Exposed Pad
- Switch Time (Ton, Toff) (Max): 100µs, 6µs
- Packaging: Tube
- Channel-to-Channel Matching (ΔRon): 100mOhm
- Voltage - Supply, Single (V+): 2.5V ~ 5.5V
- Channel Capacitance (CS(off), CD(off)): 2.5pF, 4pF
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -
- Number of Circuits: 3
- Current - Leakage (IS(off)) (Max): 250nA
- Base Part Number: MAX4996
- detail: 3 Circuit IC Switch 2:2 4Ohm 24-TQFN (4x4)
