دیتاشیت MAX20048ATGC/VY+T

مشخصات دیتاشیت

دانلود دیتاشیت MAX20048	MAX20048 Datasheet

Function: Step-Up/Step-Down
Part Status: Active
Output Configuration: Positive
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 125°C
Serial Interfaces: -
Package / Case: 24-WFQFN Exposed Pad
Clock Sync: Yes
Output Phases: 1
Packaging: Tube
Number of Outputs: 1
Voltage - Supply (Vcc/Vdd): 2V ~ 40V
Frequency - Switching: 220kHz ~ 2.2MHz
Duty Cycle (Max): -
Mounting Type: Surface Mount, Wettable Flank
Output Type: PWM
Series: Automotive, AEC-Q100
Base Part Number: MAX200
Manufacturer: Maxim Integrated
Control Features: -
Topology: Buck-Boost
Supplier Device Package: 24-SWTQFN (4x4)
detail: Buck-Boost Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 24-SWTQFN (4x4)
