MAX9202EUD+T دیتاشیت

MAX9202EUD+T

مشخصات دیتاشیت

نام دیتاشیت MAX9202EUD+T
حجم فایل 100.499 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

مشاهده دیتاشیت MAX9202EUD+T

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX9201-03 8 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX9202EUD+T
  • Output Type: 开集;开射
  • Supply Voltage: 4.75V~10.5V;2.375V~5.75V
  • Number of Elements: -
  • Operating Temperature: -40°C~+85°C
  • Input Bias Current (Ib): 5uA
  • Input Offset Voltage (Vos): 4mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 86.02dB
  • Package: TSSOP-14
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Voltage - Supply, Single/Dual (±): 4.75V ~ 10.5V, ±2.375V ~ 5.75V
  • Voltage - Input Offset (Max): 4mV @ ±5V
  • Hysteresis: -
  • Supplier Device Package: 14-TSSOP
  • CMRR, PSRR (Typ): 86.02dB CMRR, 86.02dB PSRR
  • Propagation Delay (Max): -
  • Part Status: Active
  • Type: with Latch
  • Series: -
  • Current - Quiescent (Max): 4mA, 3mA, 1.5mA
  • Base Part Number: MAX9202
  • Current - Output (Typ): -
  • Package / Case: 14-TSSOP (0.173", 4.40mm Width)
  • Packaging: Tube
  • Mounting Type: Surface Mount
  • Current - Input Bias (Max): 5µA @ ±5V
  • detail: Comparator with Latch TTL 14-TSSOP
