MAX4589CAP+ دیتاشیت

MAX4589CAP+

مشخصات دیتاشیت

نام دیتاشیت MAX4589CAP+
حجم فایل 53.186 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت MAX4589CAP+

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX4589 20 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX4589CAP+
  • Supply Voltage: 2.7V~12V;2.7V~6V
  • Switch Circuit: Double-pole, Single-throw(DPST)
  • Number of Channels: 2
  • Operating Temperature: 0°C~+70°C
  • On-State Resistance (Max): 60Ω
  • Package: SSOP-20
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Applications: Video
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Mounting Type: Surface Mount
  • Voltage - Supply, Single (V+): 2.7V ~ 12V
  • -3db Bandwidth: 200MHz
  • Supplier Device Package: 20-SSOP
  • Part Status: Obsolete
  • Voltage - Supply, Dual (V±): ±2.7V ~ 6V
  • Series: -
  • Features: Break-Before-Make, SPI, T-Switch Configration
  • Package / Case: 20-SSOP (0.209", 5.30mm Width)
  • Packaging: Tube
  • Base Part Number: MAX4589
  • detail: Video Switch IC 2 Channel 20-SSOP
