دیتاشیت LT1617ES5#TRMPBF

LT1617/-1

مشخصات دیتاشیت

نام دیتاشیت LT1617/-1
حجم فایل 146.264 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت LT1617/-1

LT1617/-1 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: boost converterType;Buck-boost type
  • Topology: Boost;Cuk
  • Datasheet: Analog Devices LT1617ES5#TRMPBF
  • Output Type: Adjustable
  • Input Voltage: 1.2V~15V
  • Output Voltage: -34V~-1.2V
  • Number of Outputs: 1
  • Output Current (Max): 300mA
  • Operating Temperature: 0°C~+70°C@(TA)
  • Synchronous Rectification: NO
  • Package: SOT-23-5
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Negative
  • Voltage - Input (Min): 1.2V
  • Voltage - Input (Max): 15V
  • Voltage - Output (Min/Fixed): -1.2V
  • Voltage - Output (Max): -34V
  • Current - Output: 300mA (Switch)
  • Frequency - Switching: -
  • Synchronous Rectifier: No
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: TSOT-23-5
  • Base Part Number: LT1617
  • detail: Boost, Cuk, Charge Pump Switching Regulator IC Negative Adjustable -1.2V 1 Output 300mA (Switch) SOT-23-5 Thin, TSOT-23-5
