DS3232MZ/V+T Datasheet
Datasheet specifications
| Datasheet's name | DS3232M |
|---|---|
| File size | 1597.54 KB |
| File type | |
| Number of pages | 23 |
Download Datasheet DS3232M |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Features: Alarm, Leap Year, Square Wave Output, SRAM
- Supplier Device Package: 8-SOIC
- Voltage - Supply, Battery: 2.3V ~ 4.5V
- Date Format: YY-MM-DD-dd
- Memory Size: 236B
- Part Status: Not For New Designs
- Operating Temperature: -40°C ~ 85°C
- Type: Clock/Calendar
- Series: Automotive, AEC-Q100
- Interface: I²C, 2-Wire Serial
- Time Format: HH:MM:SS (12/24 hr)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Current - Timekeeping (Max): 175µA @ 2.3V ~ 4.5V
- Packaging: Tape & Reel (TR)
- Voltage - Supply: 2.3V ~ 4.5V
- Base Part Number: DS3232
- Manufacturer: Maxim Integrated
- detail: Real Time Clock (RTC) IC Clock/Calendar 236B I²C, 2-Wire Serial 8-SOIC (0.154", 3.90mm Width)
