دیتاشیت LTC3240EDC-3.3#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3240-3.3/2.5 |
|---|---|
| حجم فایل | 213.293 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LTC3240-3.3/2.5 |
LTC3240-3.3/2.5 Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Function: Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Charge Pump
- Output Type: Fixed
- Number of Outputs: 1
- Voltage - Input (Min): 1.8V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Current - Output: 150mA
- Frequency - Switching: 1.2MHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 6-WFDFN Exposed Pad
- Supplier Device Package: 6-DFN (2x2)
- Base Part Number: LTC3240
- detail: Charge Pump Switching Regulator IC Positive Fixed 3.3V 1 Output 150mA 6-WFDFN Exposed Pad
