- دیتاشیت LTC3221EDC-3.3#TRMPBF
دیتاشیت LTC3221EDC-3.3#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3221(-3.3, -5) |
|---|---|
| حجم فایل | 506.632 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LTC3221(-3.3, -5) |
LTC3221(-3.3, -5) Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: -
- Datasheet: Analog Devices LTC3221EDC-3.3#TRMPBF
- Output Type: Fixed
- Input Voltage: 1.8V~4.4V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: 600kHz
- Output Current (Max): 60mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: DFN-6(2x2)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 1.8V
- Voltage - Input (Max): 4.4V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Current - Output: 60mA
- Frequency - Switching: 600kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 6-WFDFN Exposed Pad
- Supplier Device Package: 6-DFN (2x2)
- Base Part Number: LTC3221
- detail: Charge Pump Switching Regulator IC Positive Fixed 3.3V 1 Output 60mA 6-WFDFN Exposed Pad
