دیتاشیت LT1121IST-5#TRPBF

LT1121(-3.3, -5) Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT1121(-3.3, -5) Datasheet
حجم فایل 275.218 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LT1121(-3.3, -5) Datasheet

LT1121(-3.3, -5) Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices LT1121IST-5#TRPBF
  • Output Current: 150mA
  • Output Voltage: 5V
  • Dropout Voltage: 0.7V@(150mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 35V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 50uA
  • Power Supply Rejection Ratio (PSRR): 58dB@(120Hz)
  • Package: SOT-223
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 30V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.7V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 50µA
  • Current - Supply (Max): 14mA
  • PSRR: 58dB (120Hz)
  • Control Features: Enable
  • Protection Features: Over Temperature, Reverse Polarity
  • Mounting Type: Surface Mount
  • Package / Case: TO-261-4, TO-261AA
  • Supplier Device Package: SOT-223-3
  • Base Part Number: LT1121
  • detail: Linear Voltage Regulator IC 1 Output 150mA SOT-223-3
