دیتاشیت LT3502AEMS#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT3502(A) Datasheet	LT3502(A) Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT3502AEMS#TRPBF
Output Type: Adjustable
Input Voltage: 3V~40V
Output Voltage: 0.8V~32V
Number of Outputs: 1
Switching Frequency: 2.25MHz
Output Current (Max): 500mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: MSOP-10
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 32V
Current - Output: 500mA
Frequency - Switching: 2.25MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package: 10-MSOP
Base Part Number: LT3502
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 500mA 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
