- دیتاشیت LTpowerCAD II Quick Start Guide
دیتاشیت LTpowerCAD II Quick Start Guide
مشخصات دیتاشیت
| نام دیتاشیت | LTpowerCAD II Quick Start Guide |
|---|---|
| حجم فایل | 3567.647 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
LTpowerCAD II Quick Start Guide |
دانلود دیتاشیت |
|---|
سایر مستندات
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT3502EMS#TRPBF
- Output Type: Adjustable
- Input Voltage: 3V~40V
- Output Voltage: 0.8V~36V
- Number of Outputs: 1
- Switching Frequency: 1.1MHz
- Output Current (Max): 500mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: MSOP-10
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 0.8V
- Voltage - Output (Max): 36V
- Current - Output: 500mA
- Frequency - Switching: 1.1MHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-MSOP
- Base Part Number: LT3502
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 500mA 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
