دیتاشیت AT86RF231-ZFR

AT86RF231 Datasheet

مشخصات دیتاشیت

نام دیتاشیت AT86RF231 Datasheet
حجم فایل 4938.31 کیلوبایت
نوع فایل pdf
تعداد صفحات 198

دانلود دیتاشیت AT86RF231 Datasheet

AT86RF231 Datasheet Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Type: TxRx + MCU
  • RF Family/Standard: 802.15.4, General ISM > 1GHz
  • Protocol: 6LoWPAN, WirelessHART™, Zigbee®
  • Modulation: O-QPSK
  • Frequency: 2.4GHz
  • Data Rate (Max): 2Mbps
  • Power - Output: 3dBm
  • Sensitivity: -101dBm
  • Memory Size: 128B SRAM
  • Serial Interfaces: SPI
  • Voltage - Supply: 1.8V ~ 3.6V
  • Current - Receiving: 10.3mA ~ 12.3mA
  • Current - Transmitting: 7.4mA ~ 14mA
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 32-VFQFN Exposed Pad
  • Supplier Device Package: 32-QFN (5x5)
  • detail: IC RF TxRx + MCU 802.15.4, General ISM > 1GHz 6LoWPAN, WirelessHART™, Zigbee® 2.4GHz 32-VFQFN Exposed Pad
