MAX16962RAUEA/V+T دیتاشیت

MAX16962RAUEA/V+T

مشخصات دیتاشیت

نام دیتاشیت MAX16962RAUEA/V+T
حجم فایل 109.216 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت MAX16962RAUEA/V+T

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX16962 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Step-down type
  • Topology: Step-down
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX16962RAUEA/V+T
  • Output Type: Adjustable
  • Input Voltage: 2.7V~5.5V
  • Output Voltage: 0.8V~3.6V
  • Number of Outputs: 1
  • Switching Frequency: 2.2MHz
  • Output Current (Max): 4A
  • Operating Temperature: -40°C~+125°C@(TJ)
  • Synchronous Rectification: Yes
  • Package: TSSOP-16-EP
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Voltage - Input (Max): 5.5V
  • Voltage - Input (Min): 2.7V
  • Output Configuration: Positive
  • Supplier Device Package: 16-TSSOP-EP
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Frequency - Switching: 2.2MHz
  • Current - Output: 4A
  • Part Status: Active
  • Series: Automotive, AEC-Q100
  • Voltage - Output (Max): 3.6V
  • Base Part Number: MAX16962
  • Mounting Type: Surface Mount
  • Synchronous Rectifier: Yes
  • Voltage - Output (Min/Fixed): 0.8V
  • Packaging: Tube
  • detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 4A 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
