دیتاشیت MAX20010DATPO/VY+T
مشخصات دیتاشیت
| نام دیتاشیت | MAX20010C/D~ |
|---|---|
| حجم فایل | 560.467 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت MAX20010C/D~ |
MAX20010C/D~ Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Output Type: Adjustable
- Input Voltage: 3V~5.5V
- Output Voltage: 0.91V
- Number of Outputs: 1
- Switching Frequency: 2.2MHz
- Output Current (Max): 6A
- Operating Temperature: -40°C~+125°C
- Synchronous Rectification: Yes
- Package: SWTQFN-20(4x4)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 5.5V
- Voltage - Input (Min): 3V
- Output Configuration: Positive
- Supplier Device Package: 20-TQFN-EP (4x4)
- Package / Case: 20-WFQFN Exposed Pad
- Frequency - Switching: 2.2MHz
- Current - Output: 6A
- Part Status: Active
- Series: Automotive, AEC-Q100
- Voltage - Output (Max): -
- Base Part Number: MAX200
- Mounting Type: Surface Mount, Wettable Flank
- Synchronous Rectifier: Yes
- Voltage - Output (Min/Fixed): 0.91V
- detail: Buck Switching Regulator IC Positive Adjustable 0.91V 1 Output 6A 20-WFQFN Exposed Pad
