دیتاشیت LT3080EST#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT3080
|
| حجم فایل |
384.757
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices LT3080EST#TRPBF
-
Output Type:
Adjustable
-
Output Current:
1.1A
-
Output Voltage:
0V~36V
-
Dropout Voltage:
1.6V@(1.1A)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
36V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
500uA
-
Power Supply Rejection Ratio (PSRR):
75dB@(120Hz),20dB@(1MHz)
-
Package:
SOT-223
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
0V
-
Voltage - Output (Max):
36V
-
Voltage Dropout (Max):
1.6V @ 1.1A
-
Current - Output:
1.1A
-
Current - Quiescent (Iq):
500µA
-
Current - Supply (Max):
30mA
-
PSRR:
75db ~ 20dB (120Hz ~ 1MHz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-261-4, TO-261AA
-
Supplier Device Package:
SOT-223-3
-
detail:
Linear Voltage Regulator IC 1 Output 1.1A SOT-223-3
