دیتاشیت LTC3526LEDC#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3526L/LB |
|---|---|
| حجم فایل | 352.155 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LTC3526L/LB |
LTC3526L/LB Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: Boost
- Datasheet: Analog Devices LTC3526LEDC#TRMPBF
- Output Type: Adjustable
- Input Voltage: 0.5V~5V
- Output Voltage: 1.5V~5.25V
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Output Current (Max): 550mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: DFN-6(2x2)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 0.5V
- Voltage - Input (Max): 5V
- Voltage - Output (Min/Fixed): 1.5V
- Voltage - Output (Max): 5.25V
- Current - Output: 550mA (Switch)
- Frequency - Switching: 1MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 6-WFDFN Exposed Pad
- Supplier Device Package: 6-DFN (2x2)
- Base Part Number: LTC3526
- detail: Boost Switching Regulator IC Positive Adjustable 1.5V 1 Output 550mA (Switch) 6-WFDFN Exposed Pad
