LTC3309AEV#TRMPBF دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LTC3309AEV#TRMPBF	دانلود دیتاشیت

LTC3309A 26 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC3309AEV#TRMPBF
Output Type: Adjustable
Input Voltage: 2.25V~5.5V
Output Voltage: 0.5V~2.25V
Number of Outputs: 1
Switching Frequency: 3MHz
Output Current (Max): 6A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: LQFN-12-EP(2x2)
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.25V
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 0.5V
Voltage - Output (Max): 2.25V
Current - Output: 6A
Frequency - Switching: Up to 3MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 12-LQFN Exposed Pad
Supplier Device Package: 12-LQFN (2x2)
detail: Buck Switching Regulator IC Positive Programmable 0.5V 1 Output 6A 12-LQFN Exposed Pad
