LT8335IDDB#TRMPBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LT8335IDDB#TRMPBF	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType;Buck-boost type
Topology: Boost;SEPIC
Datasheet: Analog Devices LT8335IDDB#TRMPBF
Output Type: Adjustable
Input Voltage: 3V~25V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 2A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: DFN-8-EP(2x3)
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Obsolete
Output Configuration: Positive or Negative
Voltage - Input (Min): 3V
Voltage - Input (Max): 25V
Voltage - Output (Min/Fixed): 1.6V, -0.8V
Voltage - Output (Max): 28V (Switch)
Current - Output: 2A (Switch)
Frequency - Switching: 2MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-WFDFN Exposed Pad
Supplier Device Package: 8-DFN (3x2)
Base Part Number: LT8335
detail: Boost, SEPIC Switching Regulator IC Positive or Negative Adjustable 1.6V, -0.8V 1 Output 2A (Switch) 8-WFDFN Exposed Pad
