LT1086 Series دیتاشیت

LT1086 Series

مشخصات دیتاشیت

نام دیتاشیت LT1086 Series
حجم فایل 226.667 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LT1086 Series

دانلود دیتاشیت

سایر مستندات

LT1086CM-3.6#PBF 16 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices LT1086CM#TRPBF
  • Output Type: Adjustable
  • Output Current: 1.5A
  • Output Voltage: 1.25V~23.5V
  • Dropout Voltage: 1.5V@(1.5A)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 25V
  • Operating Temperature: 0°C~+125°C
  • Power Supply Rejection Ratio (PSRR): 75dB@(120Hz)
  • Package: TO-263-3
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 25V
  • Voltage - Output (Min/Fixed): 1.25V
  • Voltage - Output (Max): 23.5V
  • Voltage Dropout (Max): 1.5V @ 1.5A
  • Current - Output: 1.5A
  • PSRR: 75dB (120Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
  • Supplier Device Package: D2PAK-3
  • Base Part Number: LT1086
  • detail: Linear Voltage Regulator IC 1 Output 1.5A D2PAK-3
