- دیتاشیت LTpowerCAD II Quick Start Guide
دیتاشیت LTpowerCAD II Quick Start Guide
مشخصات دیتاشیت
| نام دیتاشیت | LTpowerCAD II Quick Start Guide |
|---|---|
| حجم فایل | 3567.647 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
LTpowerCAD II Quick Start Guide |
دانلود دیتاشیت |
|---|
سایر مستندات
LTpowerCAD II User Guide 60 pages
LT3759 Datasheet 32 pages
مشخصات فنی
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive or Negative, Isolation Capable
- Topology: Boost, Flyback, SEPIC
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 1.6V ~ 42V
- Frequency - Switching: 100kHz ~ 1MHz
- Duty Cycle (Max): -
- Synchronous Rectifier: No
- Clock Sync: Yes
- Serial Interfaces: -
- Control Features: Enable, Frequency Control, Power Good, Soft Start
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 12-TSSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 12-MSOP-EP
- Base Part Number: LT3759
- detail: Boost, Flyback, SEPIC Regulator Positive or Negative, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 12-MSOP-EP
