MAX1003CAX+T دیتاشیت

MAX1003CAX+T

مشخصات دیتاشیت

نام دیتاشیت MAX1003CAX+T
حجم فایل 58.216 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت MAX1003CAX+T

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX1003 12 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX1003CAX+T
  • Interface: Parallel
  • resolution: 6Bit
  • Supply Voltage: 5V
  • differential input: Yes
  • number of channels: 2
  • sampling frequency: 90MHz
  • Operating Temperature: 0°C~+70°C
  • Package: SSOP-36-300mil
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Part Status: Active
  • Data Interface: Parallel
  • Voltage - Supply, Digital: 3.3V
  • Sampling Rate (Per Second): 90M
  • Architecture: Pipelined
  • Supplier Device Package: 36-SSOP
  • Package / Case: 36-BSOP (0.295", 7.50mm Width)
  • Number of A/D Converters: 2
  • Packaging: Tube
  • Features: PGA, Simultaneous Sampling
  • Configuration: PGA-ADC
  • Ratio - S/H:ADC: -
  • Input Type: Differential, Single Ended
  • Reference Type: Internal
  • Number of Bits: 6
  • Mounting Type: Surface Mount
  • Series: -
  • Voltage - Supply, Analog: 5V
  • Number of Inputs: 2
  • Base Part Number: MAX1003
  • detail: 6 Bit Analog to Digital Converter 2 Input 2 Pipelined 36-SSOP
