دیتاشیت LTC201ACS#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC201A, LTC202-03 |
|---|---|
| حجم فایل | 208.104 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LTC201A, LTC202-03 |
LTC201A, LTC202-03 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices LTC201ACS#PBF
- Turn-on time: 400ns
- Turn-off time: 300ns
- Supply Voltage: 5V
- Switch Circuit: SPST(SPST)-Normally closed
- Number of Channels: 4
- On-State Resistance (Max): 125Ω
- Package: SOIC-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- Channel-to-Channel Matching (ΔRon): 6.25Ohm
- Voltage - Supply, Single (V+): 5V
- Voltage - Supply, Dual (V±): ±15V
- Switch Time (Ton, Toff) (Max): 400ns, 300ns
- -3db Bandwidth: -
- Charge Injection: 8pC
- Channel Capacitance (CS(off), CD(off)): 5pF, 12pF
- Current - Leakage (IS(off)) (Max): 5nA
- Crosstalk: -90dB @ 100kHz
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: LTC201
- detail: 4 Circuit IC Switch 1:1 125Ohm 16-SOIC
