دیتاشیت LTC3103IDD#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3103 Datasheet |
|---|---|
| حجم فایل | 442.296 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LTC3103 Datasheet |
LTC3103 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LTC3103IDD#PBF
- Output Type: Adjustable
- Input Voltage: 2.5V~15V
- Output Voltage: 0.6V~13.8V
- Number of Outputs: 1
- Switching Frequency: 1.2MHz
- Output Current (Max): 300mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: DFN-10(3x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 2.5V
- Voltage - Input (Max): 15V
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Output (Max): 13.8V
- Current - Output: 300mA
- Frequency - Switching: 1.2MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN Exposed Pad
- Supplier Device Package: 10-DFN (3x3)
- Base Part Number: LTC3103
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 300mA 10-WFDFN Exposed Pad
