- دیتاشیت PIC16LF872-I/SP
PIC16LF872-I/SP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | PIC16LF872-I/SP |
|---|---|
| حجم فایل | 29.058 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 168 |
دانلود دیتاشیت PIC16LF872-I/SP |
دانلود دیتاشیت |
|---|
سایر مستندات
MSSP Module Silicon, Data Sheet Errata 8 pages
PIC16F872 168 pages
PIC16F872 Revision A0 Errata 5 pages
PIC16F872 Revision A2 Errata 6 pages
مشخصات فنی
- RoHS: true
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit
- Datasheet: Microchip Tech PIC16LF872-I/SP
- CPU Maximum Speed: 20MHz
- GPIO Ports Number: 22
- Low-Voltage Detect: Yes
- Program Storage Size: 3.5KB
- Operating Voltage Range: 2.2V~5.5V
- Operating Temperature Range: -40°C~+85°C
- Package: SPDIP-28
- Manufacturer: Microchip Tech
- Series: PIC® 16F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 20MHz
- Connectivity: I²C, SPI
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 22
- Program Memory Size: 3.5KB (2K x 14)
- Program Memory Type: FLASH
- EEPROM Size: 64 x 8
- RAM Size: 128 x 8
- Voltage - Supply (Vcc/Vdd): 2.2V ~ 5.5V
- Data Converters: A/D 5x10b
- Oscillator Type: External
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Through Hole
- Package / Case: 28-DIP (0.300", 7.62mm)
- Supplier Device Package: 28-SPDIP
- Base Part Number: PIC16LF872
- detail: PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 3.5KB (2K x 14) FLASH 28-SPDIP
