دیتاشیت LTC3703EGN#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3703 Datasheet	LTC3703 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC3703EGN#TRPBF
Input Voltage: 9.3V~15V
Duty Cycle (Max): 93%
Number of Outputs: 1
Switching Frequency: 600kHz
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: SSOP-16-150mil
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Type: Transistor Driver
Output Configuration: Positive
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 9.3V ~ 15V
Frequency - Switching: 100kHz ~ 600kHz
Synchronous Rectifier: Yes
Clock Sync: Yes
Serial Interfaces: -
Control Features: Current Limit, Enable, Frequency Control, Soft Start
Mounting Type: Surface Mount
Package / Case: 16-SSOP (0.154", 3.90mm Width)
Supplier Device Package: 16-SSOP
Base Part Number: LTC3703
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-SSOP
