MAX5175BEEE+ دیتاشیت

MAX5175BEEE+

مشخصات دیتاشیت

نام دیتاشیت MAX5175BEEE+
حجم فایل 51.667 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

مشاهده دیتاشیت MAX5175BEEE+

دانلود دیتاشیت

سایر مستندات

Part Numbering System 7 pages

MAX5175/77 16 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX5175BEEE+
  • Operating Temperature: -40°C~+85°C
  • Package: SSOP-16-150mil-0.635mm
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Mounting Type: Surface Mount
  • Number of D/A Converters: 1
  • Data Interface: SPI
  • Voltage - Supply, Digital: 5V
  • Reference Type: External
  • Number of Bits: 12
  • Part Status: Obsolete
  • INL/DNL (LSB): ±2 (Max), ±1 (Max)
  • Differential Output: No
  • Output Type: Voltage - Buffered
  • Series: -
  • Voltage - Supply, Analog: 5V
  • Base Part Number: MAX5175
  • Supplier Device Package: 16-QSOP
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Settling Time: 12µs (Typ)
  • Packaging: Tube
  • Architecture: R-2R
  • detail: 12 Bit Digital to Analog Converter 1 16-QSOP
