LT8619IMSE#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LT8619IMSE#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT8619IMSE#PBF
Output Type: Fixed
Input Voltage: 3V~60V
Output Voltage: 0.8V~59.4V
Number of Outputs: 1
Switching Frequency: 2.2MHz
Output Current (Max): 1.2A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-16-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 60V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 59.4V
Current - Output: 1.2A
Frequency - Switching: 300kHz ~ 2.2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 16-MSOP-EP
Base Part Number: LT8619
detail: Buck Switching Regulator IC Positive Fixed 0.8V 1 Output 1.2A 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
