LT8710EFE#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LT8710EFE#PBF	دانلود دیتاشیت

LT8710 44 pages

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: boost converterType;Step-down type;Buck-boost type
Topology: Boost;Flyback;SEPIC
Datasheet: Analog Devices LT8710EFE#PBF
Input Voltage: 4.5V~80V
Duty Cycle (Max): -
Number of Outputs: 1
Switching Frequency: 750kHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-20-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Type: Transistor Driver
Output Configuration: Positive or Negative
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 4.5V ~ 80V
Frequency - Switching: 100kHz ~ 750kHz
Synchronous Rectifier: Yes
Clock Sync: Yes
Serial Interfaces: -
Control Features: Enable, Frequency Control, Soft Start
Mounting Type: Surface Mount
Package / Case: 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 20-TSSOP-EP
Base Part Number: LT8710
detail: Boost, Flyback, SEPIC Regulator Positive or Negative Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 20-TSSOP-EP
