دیتاشیت MX7845JP+T

MX7845

مشخصات دیتاشیت

نام دیتاشیت MX7845
حجم فایل 1538.973 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت MX7845

MX7845 Datasheet

مشخصات

  • Operating Temperature: 0°C ~ 70°C
  • Mounting Type: Surface Mount
  • Number of D/A Converters: 1
  • Data Interface: Parallel
  • Voltage - Supply, Digital: -
  • Reference Type: External
  • Number of Bits: 12
  • Part Status: Active
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Differential Output: No
  • Output Type: Voltage - Buffered
  • Series: -
  • Voltage - Supply, Analog: ±14.25V ~ 15.75V
  • Base Part Number: MX7845
  • Supplier Device Package: 28-PLCC (11.51x11.51)
  • Package / Case: 28-LCC (J-Lead)
  • Settling Time: 5µs
  • Packaging: Tube
  • Architecture: R-2R
  • Manufacturer: Maxim Integrated
  • detail: 12 Bit Digital to Analog Converter 1 28-PLCC (11.51x11.51)
