LT3029IMSE#PBF دیتاشیت

LT3029IMSE#PBF

مشخصات دیتاشیت

نام دیتاشیت LT3029IMSE#PBF
حجم فایل 124.531 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت LT3029IMSE#PBF

دانلود دیتاشیت

سایر مستندات

LT3029 Datasheet 20 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices LT3029IMSE#PBF
  • Output Type: Adjustable
  • Output Current: 500mA
  • Output Voltage: 1.215V~19.5V
  • Dropout Voltage: 0.46V@(500mA)
  • Output Polarity: positive
  • Number of Outputs: 2
  • Maximum Input Voltage: 20V
  • Operating Temperature: -40°C~+125°C
  • Power Supply Rejection Ratio (PSRR): 67dB@(120Hz)
  • Package: MSOP-16-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 2
  • Voltage - Input (Max): 20V
  • Voltage - Output (Min/Fixed): 1.215V
  • Voltage - Output (Max): 19.5V
  • Voltage Dropout (Max): 0.46V @ 500mA, 0.46V @ 500mA
  • Current - Output: 500mA, 500mA
  • PSRR: 67dB (120Hz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Mounting Type: Surface Mount
  • Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 16-MSOP-EP
  • Base Part Number: LT3029
  • detail: Linear Voltage Regulator IC 2 Output 500mA, 500mA 16-MSOP-EP
