LTC1407IMSE#PBF 数据手册
其他文档
LTC1407(A) 24 pages
技术规格
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC1407IMSE#PBF
- Interface: SPI
- resolution: 12
- Supply Voltage: 2.7V~3.6V
- number of channels: 2
- sampling frequency: 3MHz
- Operating Temperature: -40°C~+85°C
- Package: MSOP-10-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 12
- Sampling Rate (Per Second): 3M
- Number of Inputs: 2
- Input Type: Differential, Single Ended
- Data Interface: SPI
- Configuration: S/H-MUX-ADC
- Ratio - S/H:ADC: 2:1
- Number of A/D Converters: 1
- Architecture: Pipelined
- Reference Type: External, Internal
- Voltage - Supply, Analog: 2.7V ~ 3.6V
- Voltage - Supply, Digital: 2.7V ~ 3.6V
- Features: Simultaneous Sampling
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 10-MSOP-EP
- Mounting Type: Surface Mount
- Base Part Number: LTC1407
- detail: 12 Bit Analog to Digital Converter 2 Input 1 Pipelined 10-MSOP-EP
