دیتاشیت LTC3416EFE#PBF
مشخصات دیتاشیت
| نام دیتاشیت |
LTC3416
|
| حجم فایل |
219.067
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices LTC3416EFE#PBF
-
Output Type:
Adjustable
-
Input Voltage:
2.25V~5.5V
-
Output Voltage:
0.8V~5V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
4A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
TSSOP-20-EP
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.25V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
5V
-
Current - Output:
4A
-
Frequency - Switching:
1MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
20-TSSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
20-TSSOP-EP
-
Base Part Number:
LTC3416
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 4A 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
