دیتاشیت DS32KHZ/DIP#
مشخصات دیتاشیت
| نام دیتاشیت | DS32KHZ-DS32KHZS |
|---|---|
| حجم فایل | 449.844 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت DS32KHZ-DS32KHZS |
DS32KHZ-DS32KHZS Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Crystal Oscillator/Oscillator/Resonator/Temperature Compensated Crystal Oscillators (TCXOs)
- Frequency: 32.768kHz
- Output Type: CMOS
- Supply Voltage: 5V
- Frequency Stability: ±7.5ppm
- Supply Current (Max): 220uA
- Operating Temperature: 0°C~+70°C
- Package: -
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Function: -
- Current - Supply (Disable) (Max): -
- Ratings: -
- Current - Supply (Max): 220µA
- Absolute Pull Range (APR): -
- Height - Seated (Max): 0.315" (8.01mm)
- Package / Case: 14-DIP Module
- Part Status: Obsolete
- Output: CMOS
- Base Resonator: Crystal
- Type: TCXO
- Series: DS
- Mounting Type: Through Hole
- Size / Dimension: 0.860" L x 0.460" W (21.84mm x 11.68mm)
- Packaging: Tube
- Voltage - Supply: 5V
- Base Part Number: DS32KHZ
- detail: 32.768kHz TCXO CMOS Oscillator 5V 14-DIP Module
