دیتاشیت VCC1-1545-49M1520000
مشخصات دیتاشیت
| نام دیتاشیت | VCC1-1545-49M1520000 |
|---|---|
| حجم فایل | 735.518 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت VCC1-1545-49M1520000 |
VCC1-1545-49M1520000 Datasheet |
|---|
مشخصات
- RoHS: true
- Ratings: -
- Category: Crystal Oscillator/Oscillator/Resonator/Oscillators
- Datasheet: Microchip Tech VCC1-1545-49M1520000
- Frequency: 49.152MHz
- Output Type: CMOS
- Supply Voltage: 3.3V
- Supply Current (Max): 20mA
- Operating Temperature: -40°C~+85°C
- Package: SMD7050-4P
- Manufacturer: Microchip Tech
- Series: VCC1
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Base Resonator: Crystal
- Type: XO (Standard)
- Function: Enable/Disable
- Output: CMOS
- Voltage - Supply: 3.3V
- Frequency Stability: ±50ppm
- Absolute Pull Range (APR): -
- Spread Spectrum Bandwidth: -
- Current - Supply (Max): 20mA
- Mounting Type: Surface Mount
- Package / Case: 4-SMD, No Lead
- Size / Dimension: 0.276" L x 0.197" W (7.00mm x 5.00mm)
- Height - Seated (Max): 0.075" (1.90mm)
- Current - Supply (Disable) (Max): 30µA
- detail: 49.152MHz XO (Standard) CMOS Oscillator 3.3V Enable/Disable 4-SMD, No Lead
