- دیتاشیت LT3797EUKG#PBF
LT3797EUKG#PBF دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LT3797EUKG#PBF |
|---|---|
| حجم فایل | 114.688 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت LT3797EUKG#PBF |
دانلود دیتاشیت |
|---|
سایر مستندات
LT3797 Datasheet 36 pages
مشخصات فنی
- RoHS: true
- Type: DC-DCController
- Dimming: Analog;PWM
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 3
- Features: -
- Topology: Flyback;SEPIC;Step-down;boost converter
- Datasheet: Analog Devices LT3797EUKG#PBF
- Input Voltage: 2.5V~40V
- Output Voltage: -
- Switch Frequency: 100kHz~1MHz
- Operating temperature: -40°C~+125°C
- Package: QFN-53(7x8)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Internal Switch(s): No
- Number of Outputs: 3
- Voltage - Supply (Min): 2.5V
- Voltage - Supply (Max): 40V
- Voltage - Output: -
- Current - Output / Channel: -
- Frequency: 100kHz ~ 1MHz
- Applications: Automotive, Lighting
- Mounting Type: Surface Mount
- Package / Case: 52-WFQFN Exposed Pad
- Supplier Device Package: 52-QFN (7x8)
- Base Part Number: LT3797
- detail: LED Driver IC 3 Output DC DC Controller Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) Analog, PWM Dimming 52-QFN (7x8)
