MX7847JR+T دیتاشیت

MX7847JR+T

مشخصات دیتاشیت

نام دیتاشیت MX7847JR+T
حجم فایل 48.384 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت MX7847JR+T

دانلود دیتاشیت

سایر مستندات

MX7837,47 12 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices Inc./Maxim Integrated MX7847JR+T
  • Interface: Parallel
  • resolution: 12
  • output type: Voltage-缓冲
  • built-up time: 4us
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: 0°C~+70°C
  • Package: SOIC-24-300mil
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Mounting Type: Surface Mount
  • Number of D/A Converters: 2
  • Data Interface: Parallel
  • Voltage - Supply, Digital: -
  • Reference Type: External
  • Number of Bits: 12
  • Part Status: Active
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Differential Output: No
  • Series: -
  • Voltage - Supply, Analog: ±11.4V ~ 16.5V
  • Base Part Number: MX7847
  • Supplier Device Package: 24-SOIC
  • Package / Case: 24-SOIC (0.295", 7.50mm Width)
  • Settling Time: 4µs (Typ)
  • Packaging: Tube
  • Architecture: R-2R
  • detail: 12 Bit Digital to Analog Converter 2 24-SOIC
