LTC7150SEY#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LTC7150SEY#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC7150SEY#PBF
Output Type: Adjustable
Input Voltage: 3.1V~20V
Output Voltage: 0.6V~5.5V
Number of Outputs: 1
Switching Frequency: 1MHz
Output Current (Max): 20A
Operating Temperature: 0°C~+85°C@(TJ)
Synchronous Rectification: Yes
Package: BGA-42
Manufacturer: Analog Devices
Series: -
Packaging: Tray
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3.1V
Voltage - Input (Max): 20V
Voltage - Output (Min/Fixed): 0.6V
Voltage - Output (Max): 5.5V
Current - Output: 20A
Frequency - Switching: 1MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 42-LFBGA
Supplier Device Package: 42-BGA (6x5)
Base Part Number: LTC7150
detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 20A 42-LFBGA
