- LTC3115-2 Datasheet
LTC3115IDHD-2#PBF Datasheet
Datasheet specifications
| Datasheet's name | LTC3115-2 Datasheet |
|---|---|
| File size | 2810.698 KB |
| File type | |
| Number of pages | 42 |
Download Datasheet LTC3115-2 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Function: Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Buck-Boost
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 2.2V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 2.7V
- Voltage - Output (Max): 40V
- Current - Output: 800mA, 2A
- Frequency - Switching: 100kHz ~ 2MHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 16-WFDFN Exposed Pad
- Supplier Device Package: 16-DFN (5x4)
- Base Part Number: LTC3115
- detail: Buck-Boost Switching Regulator IC Positive Adjustable 2.7V 1 Output 800mA, 2A 16-WFDFN Exposed Pad
