LT8631HFE#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LT8631HFE#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT8631HFE#PBF
Output Type: Adjustable
Input Voltage: 3V~100V
Output Voltage: 0.8V~60V
Number of Outputs: 1
Switching Frequency: 1MHz
Output Current (Max): 1A
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-20
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 100V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 60V
Current - Output: 1A
Frequency - Switching: 100kHz ~ 1MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 20-TSSOP (0.173", 4.40mm Width), 16 Leads, Exposed Pad
Supplier Device Package: 20-TSSOP-EP
Base Part Number: LT8631
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 1A 20-TSSOP (0.173", 4.40mm Width), 16 Leads, Exposed Pad
