DG302AAK/883B Datasheet
Datasheet specifications
| Datasheet's name | DG302AAK/883B |
|---|---|
| File size | 77.419 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet DG302AAK/883B |
Download Datasheet |
|---|
Other documentations
DG300A-303A 11 pages
DG30xAx/883B Milspecs 5 pages
Technical specifications
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated DG302AAK/883B
- Switch Circuit: -
- Package: DIP-14
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 2:1
- Part Status: Active
- Charge Injection: 12pC
- -3db Bandwidth: -
- Operating Temperature: -55°C ~ 125°C (TA)
- Voltage - Supply, Dual (V±): ±5V ~ 18V
- Supplier Device Package: 14-CDIP
- Package / Case: 14-CDIP (0.300", 7.62mm)
- Switch Time (Ton, Toff) (Max): 300ns, 250ns
- Packaging: Tube
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): -
- Channel Capacitance (CS(off), CD(off)): 14pF, 14pF
- Mounting Type: Through Hole
- Series: -
- Crosstalk: -74dB @ 500kHz
- Number of Circuits: 2
- Current - Leakage (IS(off)) (Max): 1nA
- Base Part Number: DG302
- On-State Resistance (Max): 50Ohm
- detail: 2 Circuit IC Switch 2:1 50Ohm 14-CDIP
