دیتاشیت ATXMEGA64B3-ANR
مشخصات دیتاشیت
| نام دیتاشیت | ATXMEGA128B3, 64B3 |
|---|---|
| حجم فایل | 6448.569 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 144 |
دانلود دیتاشیت ATXMEGA128B3, 64B3 |
ATXMEGA128B3, 64B3 Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 32KB
- CPU Core: AVR
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): -
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 36
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;LCD/LED Driver
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 32KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.6V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: TQFP-64(14x14)
- Manufacturer: Microchip Tech
- Series: AVR® XMEGA® B3
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Core Processor: AVR
- Core Size: 8/16-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
- Number of I/O: 36
- Program Memory Size: 64KB (32K x 16)
- EEPROM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 1.6V ~ 3.6V
- Data Converters: A/D 8x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-TQFP
- Supplier Device Package: 64-TQFP (14x14)
- Base Part Number: ATXMEGA64
- detail: AVR AVR® XMEGA® B3 Microcontroller IC 8/16-Bit 32MHz 64KB (32K x 16) FLASH 64-TQFP (14x14)
