LTM4625IY دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LTM4625IY
|
|
حجم فایل
|
106.168
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
26
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Datasheet:
Analog Devices LTM4625IY
-
Output Channel:
1
-
Output Voltage:
0.6V~5.5V
-
Input Voltage(DC):
4V~20V
-
Output Current (Max):
5A
-
Conversion Efficiency:
91%
-
Package:
BGA-25
-
Manufacturer:
Analog Devices
-
Series:
µModule®
-
Packaging:
Tray
-
Part Status:
Active
-
Type:
Non-Isolated PoL Module
-
Number of Outputs:
1
-
Voltage - Input (Min):
4V
-
Voltage - Input (Max):
20V
-
Voltage - Output 1:
0.6 ~ 5.5V
-
Voltage - Output 2:
-
-
Voltage - Output 3:
-
-
Current - Output (Max):
5A
-
Applications:
ITE (Commercial)
-
Features:
OCP, OTP, OVP, UVLO
-
Operating Temperature:
-40°C ~ 125°C
-
Efficiency:
91%
-
Mounting Type:
Surface Mount
-
Package / Case:
25-PowerBBGA Module
-
Size / Dimension:
0.25" L x 0.25" W x 0.20" H (6.3mm x 6.3mm x 5.0mm)
-
Supplier Device Package:
25-BGA (6.25x6.25)
-
Base Part Number:
LTM4625
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.6 ~ 5.5V 5A 4V - 20V Input
