دیتاشیت LTC2512IDKD-24#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2512-24 Datasheet |
|---|---|
| حجم فایل | 709.184 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت LTC2512-24 Datasheet |
LTC2512-24 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2512IDKD-24#PBF
- Interface: SPI
- resolution: 24Bit
- Supply Voltage: 2.375V~2.625V
- differential input: Yes
- number of channels: 1
- sampling frequency: 1.6MHz
- Operating Temperature: -40°C~+85°C
- Package: DFN-24(4x7)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 24
- Sampling Rate (Per Second): 1.6M
- Number of Inputs: 1
- Input Type: Differential
- Data Interface: SPI
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: External
- Voltage - Supply, Analog: 2.375V ~ 2.625V
- Voltage - Supply, Digital: 2.375V ~ 2.625V
- Features: -
- Package / Case: 24-WFDFN Exposed Pad
- Supplier Device Package: 24-DFN (7x4)
- Mounting Type: Surface Mount
- Base Part Number: LTC2512
- detail: 24 Bit Analog to Digital Converter 1 Input 1 SAR 24-DFN (7x4)
