MX574ALEWI+ Datasheet

MAX174, MX574A,674A

Datasheet specifications

Datasheet's name MAX174, MX574A,674A
File size 1369.273 KB
File type pdf
Number of pages 18

Download Datasheet MAX174, MX574A,674A

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Part Status: Active
  • Data Interface: Parallel
  • Voltage - Supply, Digital: 5V
  • Sampling Rate (Per Second): 40k
  • Operating Temperature: -40°C ~ 85°C
  • Architecture: SAR
  • Supplier Device Package: 28-SO
  • Package / Case: 28-SOIC (0.295", 7.50mm Width)
  • Number of A/D Converters: 1
  • Packaging: Tube
  • Features: -
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Input Type: Single Ended
  • Reference Type: External, Internal
  • Number of Bits: 12
  • Mounting Type: Surface Mount
  • Series: -
  • Voltage - Supply, Analog: ±11.4V ~ 16.5V
  • Number of Inputs: 1
  • Base Part Number: MX574
  • Manufacturer: Maxim Integrated
  • detail: 12 Bit Analog to Digital Converter 1 Input 1 SAR 28-SO
